Model
cyclops 335

Item specifics

Detector Type
Vox Microbolometer
Resolution / Pixel Spacing
384x288/12um
NETD
≤40mk@300k
FOV
10.5°x 7.9°
Diopter Control
-5~+5
Working Temperature
-20℃~+55℃
Size
67mm×63mm×190mm
Weight
470g (with battery)

Product review

Description

thermal imaging scope
thermal vision monocular
wifi monocular
oled thermal monocular
night vision monocular
waterproof monocular
night vision scope

Technical Datasheet:

Sensor Parameters

Items / Specification
CYCLOPS 335

Detector Type

Vox Microbolometer

Resolution / Pixel Spacing

384x288/12um

NETD

≤40mk@300k

Frame Rate

50Hz

Spectral Range

8~14μm

Lens

35mm (F#1.0, manual focus)

FOV

7.5°x 5.6°

Image Processing

Digital Zoom

1~6x continuous

Color Palette

5+

Noise Reduction

3D noise reduction

Image Enhancement

IDE、HDR

Display

OLED

0.39 inch,1024×768 resolution

Diopter Control

-5~+5

Eye Distance

40mm

Function

OLED

8 modes

Language

English

Reticle

6+, adjustable coordinates
Memory Card
16G

Heat Track

Yes

AI Distance Measurement

Yes
Laser Indicator
Yes

Photo, Record, Playback

Yes

GPS

Yes

Power

Battery Type

Internal Li-Ion Cell(18650 Li battery x 2)

Battery Life

Continuous working time≥ 12h
Interface

Type-C

Power charge, read data, output analog video

WI-FI

Two-way Wi-Fi connection, APP remote control

Environmental Parameters

Working Temperature

-20℃~+55℃

Protection Level

IP67,1 meter drop resistance

Physical Parameters

Weight

490g (with battery)

Size

67mm×63mm×190mm

Accessories

External Cable

Analog video cable, USB data cable

Other Accessory

Wrist strap, plush bag, user manual
Product Application
hunting night vision
