hot sale binocular telescope water resistance binocular TH650M
hot sale binocular telescope water resistance binocular TH650M
hot sale binocular telescope water resistance binocular TH650M
hot sale binocular telescope water resistance binocular TH650M
hot sale binocular telescope water resistance binocular TH650M
Model
TH650

Item specifics

Detector Type
Uncooled Micro Bolometer
Resolution / Pixel Spacing
640x480/17um
NETD
< 60mK
FOV
7.0°×5.3°
Lens
52mm, F# 1.0
Start-up
<5 seconds
Focus
Manual
Zoom
2×~4×

Product review

Description

        Product Features


           1. IP66

               The IP night vision binocular has IP 66 dustproof and waterproof rating. It always keeps your binocular work in a good condition.

           2. 24 hours suitable

               with the high sensitivity thermal core, you can use both in day and night for security and serveillance

           3. Multiple devices can be connected

              0.6 LED display, can be contacted with external display device

Technical Datasheet:

Sensor Parameters

Items / Specification
TH350M
TH650M
Detector
Uncooled Micro Bolometer

Resolution / Pixel Spacing

384x288/17μm
640x480/17μm

NETD

< 60mK

Frame Rate

50Hz

Spectral Range

8~14μm

Pole

Hot White/Hot Black(pseudo-color)
Contrast/Brightness
Auto/Manual
Reticle
moveable、storable、graphic editable

Image Processing

Start-up

<5 seconds
Noise Reduction
Digital filtering
image adjustment
Auto / Manual
E-Zoom
2×~4×

Infrared Optical parameters

Focus mode

Manual

Objective

52mm, F# 1.0

Field of view

7.0°×5.3°

Focus  Range


5m~∞

Display

800X600 monocular 0.6’LED

System parameters

No Shutter









External  interface

Video Output:USB2.0

System weight

<1.3kg(include Battery)
Mount Adaptor
1/4' Standard tripod mounting

Power supply

Power Supply
1×26650 rechargeable lithium ion ,3.7V@5000mAH;
Power Consumption
<2.5W
Operating Time
>8 hours
Video Recording

Storage




Recording format 640×480;Built-in 16G

External interface

Video output ;USB2.0

Environmental

Protect standard


IP66
Operating Temperature
-30℃~+55℃
Storage Temperature
-40℃~+65℃
Humidity
5%~95%(Non-Condensing)
Vibration
Sweep frequency:5-200-5Hz,Acceleration 2.5g

Impact

30g/11ms Half sine wave

Physical parameters

Dimension(mm)
220×170×68(L×W×H)
Net weight
1.2Kg(include Battery and wristband)
housing
Full of Aluminum alloy
suitcase Dimension (mm)
460×350×180(L×W×H)
Product Application
