infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
infrared thermal imaging camera outdoor hunting telescope thermal scope TM600-A
Model
TM600-A

Item specifics

Detector Type
FPA
Resolution / Pixel Spacing
640x480/17um
Spectral range
8~14μm
Display
OLED 0.5 inches
Lens
55mm F#=1.0
Focus Mode
Manual
Electronic zoom
1~8 x Continuous zoom
Magnification
12x

Product review

Description


●  1~8 x continuous zoom and 12x magnification
●  Support picture in picture, thermal tracking and edge detection
●  0.5 inches OLED display makes you see target freely
●  Max 64G storage capacity help you keep every photo and video

Technical Datasheet:

Sensor Parameters

Items / Specification
TM300-A
TM600-A
Detector
Uncooled Microbolometer FPA (Amorphous Silicon)

Resolution / Pixel Spacing

384x288/17μm
640x480/17μm

Spectral Range

8~14μm

Lens parameters

55mm F#=1.0

Focus Mode

manual
Electronic zoom
1~8 x Continuous zoom
Picture in Picture
Support
Thermal tracking
Support

Edge detection

Support
Pseudo color pattern
9 types
Reticle
8 types

Eyepiece parameters

 Display








OLED 0.5 inches

Contrast

10000:1

Eye relief

26mm
Magnification
12x
OLED resolution
1024×768

Image storage

Video format

MP4

Image resolution

768×576 D1

Storage capacity

Standard 8G (optional 64G)

Physical characteristics






Product size

220×85×80mm

Protection

IP66

Operating temperature

-45℃~+60
Storage temperature
-45℃~+60

Input voltage

DC5V 1A

Power consumption

Average power consumption 2W
Battery capacity
26500 Rechargeable Li-ion battery  3.7V3200mAH
Working hours
Continuous working time >4 hours
Product weight
1100g
Detection distance index
For people 1.8x0.5m

Detection distance

1000m standard weather conditions

Identification distance




380m standard weather conditions

Detection distance index

For vehicles 2.3x2.3m
Detection distance
2000m (standard weather conditions)

Identification distance

875m (standard weather conditions)
Product Application
